Multi-Function 50bag/min Box Filling Machine for Precise and Consistent Filling

Ask Lasest Price
Brand Name :	3A
Supply Ability :	10 Set/Sets per Month
Price :	$18,000.00/sets >=1 sets

Add to Cart

Product Details
Company Profile

Multi-Function 50bag/min Box Filling Machine for Precise and Consistent Filling

120 Automatic Box filling machine

Feeding - Opening box - entering box - sealing box - output

The machine is a high-tech product integrating optical, electrical, gas and machine. The machine is suitable for automatic packing of a variety of products, its working process: transfer material - spread-box - transfer box - loading material - closed box mouth.

Linear machine speed	50-80 pcs/min
Paper box requirements	220-350g/ m²
Paper box size	L(80-210)W(20-90)H(10-60)mm
Power	220V/380V,50HZ 1.5kw
Overall dimensions	L3.1mW1.25mH1.7m
Weight	1300kg
Air pressure	≥0.6Mpa
Air consumption	20 m3/H

Performance Characteristics

1. The shape of the model is all 304 stainless steel cover, the transmission part is designed with overload protection function, and set up the emergency stop device, the control system uses the man-machine interface video screen, to ensure the personal safety of the operator.

2. Servo/stepper motor and touch screen, PLC programmable control system, human-machine interface display operation more clear and simple, high degree of automation, more user-friendly.

3. Photoelectric induction switch automatic detection and tracking system, no product no suction box, saving packaging materials.

4. Large packaging range, convenient adjustment, various sizes can be quickly converted. 5. No need to change the mold to change the specifications, just adjust the realization. 6. When there is no product or the product supply is not in place, the machine will idle and not push the product. When the product is restored to the supply, the machine will run automatically, and the product will stop automatically if the box is not in place. 7. The two ends of the carton are automatically sealed, and the finished products are transported out through the belt. The finished products have good effect.

8. Automatic display of packing speed and count: 9. According to customer requirements, the upturning type safety protective cover is adopted, which is easy to operate and beautiful in appearance. 10. Can be connected with aluminum labeling machine, inkjet printer, online weighing instrument and other equipment, to achieve linkage production; According to customer requirements, the hot melt glue machine can be selected to use hot melt glue spray sealing box.

List of main components

NO	Name	Brand	Quantity
1	PLC	Omron, Japan	1
2	Encoder	Omron, Japan	1
4	Frequency converter	Omron, Japan	1
9	Button	Schneider, France	3
11	Intermediate relay	Omron, Japan	5
12	AC contactor	Schneider, France	1
13	Proximity switch	Omron, Japan	2
17	Sensor	Omron, Japan	1

Details

Material conveying chain

Carton bin
